Technical Specifications
| Engine | |
|---|---|
| Engine Type | V-twin, 8 valve, SOHC, EFI |
| Engine Displacement | 800 cc |
| Compression Ratio | 10.3:1 |
| Fuel System | Delphi® Electronic Fuel Injection |
| Bore & Stroke | 91 × 61.5 |
| Max Power Output | 62 HP @ 6700 RPM |
| Max Torque | 53 lb-ft @ 6000 RPM |
| Cooling System | Liquid Cooled |
| Ignition | ECU |
| Starting | Electric |
| Transmission | CVTech driven clutch |
| Wheels, Suspension, and Brakes | |
| Wheels (Front) | 14 × 7.0 Aluminum Alloy |
| Wheels (Rear) | 14 × 8.0 Aluminum Alloy |
| Tires (Front) | 26 × 9-14 |
| Tires (Rear) | 26 × 11-14 |
| Suspension (Front/Rear) | Double A-arm, Independent |
| Shock Absorber (Front/Rear) | Spring pre-load/compression and rebound adjustable |
| Brakes | 4 wheel Hydraulic Disc |
| Dimensions and Weight | |
| Length | 113 in |
| Width | 50 in |
| Height | 70 in |
| Wheelbase | 80 in |
| Ground Clearance | 11.2 in |
| Fuel Capacity | 7.13 gallons |
| Complete Weight | 1,228 lbs |
| Accessories | |
| Fuel Tank Lock | Standard |
| Hitch / Receiver | 2 in |
| Winch | 3000 lbs |
Features
- High performance CVTech driven clutch with wet clutch engagement and engine brake
- Contoured roof–standard
- High intensity projector-beam headlights
- Reliable Yuasa® AGM (Absorbent Glass Mat) sealed battery-standard
- Front & rear stainless steel bumpers
- CFMOTO 14” Alloy Wheels
- Double A-arms with adjustable coil-over nitrogen gas shocks
- Cargo and Side Nets-standard
- 3-point seat belts with alarm light
- Tilt steering wheel
- Multi-function Digital Dash
- 3000 lb. winch—standard
- 2” hitch receiver with power socket
- Windshield-optional
Color options
MSRP (2016)
$9,999
$10,799 with EPS
Plus Freight ($575) *, Dealer Setup, Taxes and License
* Continental USA only
