Technical Data / Specifications
| Fuel | |
|---|---|
| Recommended fuel quality | Premium grade unleaded fuel (max. 5% ethanol, E5) 91 AKI (98 ROZ/RON) 93 AKI |
| Alternative fuel quality | Super unleaded (max. 10% ethanol, E10) 89 AKI (95 ROZ/RON) 90 AKI |
| Usable fuel quantity | Approx. 4.6 gal (Approx. 17.5 l) |
| Fuel reserve | Approx. 1.1 gal (Approx. 4 l) |
| Fuel consumption | 35 mpg (6.7 l/100 km), according to WMTC |
| Engine Oil | |
| Engine oil, capacity | Approx. 3.7 quarts (Approx. 3.5 l), with filter replacement |
| Specification | SAE 5W-40, API SL/JASO MA2, Additives prohibited (e.g., molybdenum-based substances) |
| Engine oil, quantity for topping up | max 0.8 quarts (max 0.8 l), Difference between MIN and MAX |
| Engine | |
| Engine number location | Lower right section of crankcase, behind coolant pump |
| Engine type | 104EA |
| Engine design | Water/oil-cooled 4-cylinder four-cycle in-line engine with four valves per cylinder and two overhead cams |
| Displacement | 999 cc (999 cm3) |
| Cylinder bore | 3.1 in (80 mm) |
| Piston stroke | 2 in (49.7 mm) |
| Compression ratio | 13:1 |
| Rated output | 199 hp (146 kW), at engine speed: 13500 min-1 |
| Torque | 83 lb/ft (113 Nm), at engine speed: 10500 min-1 |
| Maximum engine speed | max 14200 min-1 |
| Idle speed | 1270 min-1, Engine at operating temperature |
| Emission standard | Euro 4 |
| Clutch | |
| Clutch design | Multi-disk oil-bath clutch, slipper clutch |
| Transmission | |
| Transmission design | Claw-shifted 6-speed transmission integrated in engine housing |
| Transmission gear ratios | 1.652 (76:46 teeth), Primary gear ratio … 1.261 (29:23 teeth), 6th gear |
| Rear-wheel Drive | |
| Type of final drive | Chain drive |
| Type of rear suspension | Two-arm aluminum swinging arm |
| Number of teeth of rear-wheel drive | 17:45 |
| Secondary gear ratio | 2.647 |
| Frame | |
| Frame design | Aluminum composite bridge frame, load-sharing engine |
| Location of type plate | Frame at front right on steering head |
| Location of the vehicle identification number | Frame at front right on steering head |
| Suspension | |
| Type of front suspension | Upside-down telescopic forks |
| Spring travel, front | 4.7 in (120 mm), on wheel |
| Type of rear suspension | Two-arm aluminum swinging arm |
| Spring travel, rear | 4.7 in (120 mm), on wheel |
| Brakes | |
| Type of front brake | Hydraulic radially operated twin disc brake with 4-piston radial fixed caliper and floating brake discs |
| Front brake pad material | Sintered metal |
| Front brake-disk thickness | 0.2 in (5.0 mm), New min 0.18 in (min 4.5 mm), Wear limit |
| Free travel of brake actuation | 0.02…0.06 in (0.6…1.4 mm), at piston |
| Type of rear brake | Hydraulically operated disc brake with 1-piston floating caliper and fixed brake disc |
| Rear brake pad material | Organic |
| Rear brake-disk thickness | 0.2 in (5.0 mm), New min 0.18 in (min 4.5 mm), Wear limit |
| Blow-by clearance of footbrake lever | 0.08…0.12 in (2…3 mm), between stop and footbrake lever |
| Wheels and Tires | |
| Recommended tire combinations | Available from authorized BMW Motorrad retailer or at bmw-motorrad.com |
| Speed category of front/rear tires | W, minimum requirement: 168 mph (270 km/h) |
| Front wheel design | Aluminum cast wheel |
| Front-wheel rim size | 3.50″ x 17″ |
| Front tire designation | 120/70 ZR 17 |
| Load index for front tire | 58 |
| Permissible front-wheel imbalance | max 0.2 oz (max 5 g) |
| Balance weight for front wheel | max 2.8 oz (max 80 g) |
| Rear wheel design | Aluminum cast wheel |
| Rear-wheel rim size | 6.0″ x 17″ |
| Rear tire designation | 190/55 ZR 17 with forged wheelsOE 200/55 ZR 17 |
| Load index for rear tire | 75 |
| Permissible rear-wheel imbalance | max 1.6 oz (max 45 g) |
| Balance weight for rear wheel | max 2.8 oz (max 80 g) |
| Tire Pressure | |
| Tire pressure, front | 36.3 psi (2.5 bar), with tire cold |
| Tire pressure, rear | 42.1 psi (2.9 bar), with tire cold |
| Electrical System | |
| Fuses | Fuse 1: 10 A, Instrument cluster … Main fuse: 40 A |
| Battery design | AGM battery (Absorbent Glass Mat) with HP batteryOE Lithium ion battery |
| Battery voltage | 12 V with HP batteryOE 12.8 V |
| Battery capacity | 9 Ah with HP batteryOE 5 Ah |
| Spark plugs | NGK LMAR9D-J |
| Light sources | Bulb for high-beam headlight: H7 / 12 V / 55 W … Light source for license plate light: W5W / 12 V / 5 W |
| Dimensions | |
| Motorcycle length | 80.7 in (2050 mm), over splash guard |
| Motorcycle height | 44.9 in (1140 mm), over windshield, at DIN unladen weight |
| Motorcycle width | 32.5 in (826 mm), over mirrors |
| Rider’s seat height | 32.1 in (815 mm), Without driver |
| Rider’s inside-leg arc, heel to heel | 71.1 in (1805 mm), Without driver |
| Weights | |
| Vehicle curb weight | 459 lbs (208 kg), DIN unladen weight, ready for road, 90% full tank of gas, without OE |
| Permissible gross weight | 897 lbs (407 kg) |
| Maximum payload | 439 lbs (199 kg) |
