Ducati 100 Scrambler

Ducati 100 Scrambler
Manufacturer Ducati
Production 1970-1971
Class On/off road
Engine 98 cc (6.0 cu in) single cylinder Air-cooled two stroke
Bore / stroke 52 mm × 46 mm (2.0 in × 1.8 in)
Compression ratio 11.2:1
Top speed 100 km/h (62 mph)
Power 6.27 bhp (4.68 kW) @ 6,000 rpm
Transmission Multiplate wet clutch, 4 speed
Frame type Duplex cradle
Suspension Front: telescopic forks
Rear: swinging arm
Brakes Drum front & rear
Tyres Front: 250×18
Rear: 250×17
Wheelbase 1,180 mm (46 in)
Dimensions L: 1,840 mm (72 in)
W: 800 mm (31 in)
Seat height 730 mm (29 in)
Weight 67 kg (148 lb) (dry)
Footnotes / references

The Ducati 100 Scrambler is an on/off-road 98 cc (6.0 cu in) single cylinder two stroke motorcycle produced by the Italian manufacturer Ducati in 1970 and 1971. The model was produced to take advantage of the dirt bike craze in Italy at the time. The model used many parts from existing models, keeping R&D costs down. A smaller engined version, the 50 Scrambler, was also produced. The model did not sell well and was soon dropped.

Technical details

Engine and transmission

The engine of the Scrambler was taken from the Mountaineer. It was a piston ported two stroke of unit construction and had an alloy head and alloy barrel with a chrome-plated bore. Bore and stroke were 52 mm × 46 mm (2.0 in × 1.8 in) giving a displacement of 98 cc (6.0 cu in). Compression ratio was 11.2:1 and claimed power output was 6.27 bhp (4.68 kW) @ 6,000 rpm.

Fuel was delivered by a 24 mm Dell’Orto UBF carburettor and ignition was by flywheel magneto. Petrol/oil mix provided lubrication.

Primary drive was by helical gears to a multi-plate wet clutch and a 4 speed gearbox. Chain drive took power to the rear wheel.

Cycle parts

The duplex frame was the same as that used on the Cadet and SL models. Rear suspension was by swinging arm with twin Marzocchi shock absorbers. At the front Ceriani pattern Marzocchi telescopic forks were fitted. Brakes were 118 mm (4.6 in) diameter drums front and rear. The bike had a high level exhaust and was finished in yellow and black.

References

Bibliography

  • Falloon, Ian (July 2016). The Complete Book of Ducati Motorcycles: Every Model Since 1946. Minneapolis, MN: Motorbooks. ISBN 978-0-7603-5022-5.

  • Scialino, Giorgio (22 December 2017). “Ducati Scrambler 50 e 100, sorelle minori” [Ducati Scrambler 50 and 100, younger sisters]. www.inmoto.it (in Italian).
  • Walker, Mick (2002). Illustrated Ducati Buyer’s Guide. MotorBooks International. ISBN 978-1-61059-045-7.
  • Walker, Mick (2003). Ducati Singles Restoration. MotorBooks International. ISBN 978-1-61060-919-7.
