2011 Harley-Davidson FXDC DYNA SUPER GLIDE CUSTOM

DIMENSIONS
Length 92.9 in. (2360 mm)
Overall Width 38.9 in. (988 mm)
Overall Height 48.5 in. (1232 mm)
Seat Height (Laden) 26.3 in. (668 mm)
Seat Height (Unladen) 26.5 in. (673 mm)
Ground Clearance 4.6 in. (117 mm)
Rake (steering head) 29°
Fork Angle 29°
Trail 4.7 in. (119 mm)
Wheelbase 64.2 in. (1631 mm)
Front Tire 100/90-19 57H (Michelin® Scorcher™ “31”)
Rear Tire 160/70-17 73V (Michelin® Scorcher™ “31”)
Fuel Capacity 5.0 gal. (18.9 L)
Oil Capacity (with filter) 3.0 qts. (2.8 L)
Transmission Capacity 1.0 qts.
Primary Chain Case Capacity 1.0 qts.
Weight (As Shipped) 645 lbs. (292.6 kg)
Weight (In Running Order) 676 lbs. (306.7 kg)
Gross Vehicle Weight Rating 1085 lbs. (492.2 kg)
Gross Axle Weight Rating (Front) 390 lbs. (176.9 kg)
Gross Axle Weight Rating (Rear) 695 lbs. (315.3 kg)
ENGINE
Engine Type Air-cooled, Twin Cam 96™
Valves Pushrod-operated, overhead valves with hydraulic self-adjusting lifters; 2 valves per cylinder
Bore x Stroke 3.75 in. x 4.38 in. (95.3 mm x 111.3 mm)
Displacement 96 cu. in. (1584 cc)
Compression Ratio 9.2:1
Fuel System Electronic Sequential Port Fuel Injection (ESPFI)
Air Cleaner Fiberglass Media, washable
Lubrication System Pressurized, dry-sump
DRIVETRAIN
Primary Drive Chain, 34/46 ratio
Final Drive Belt, 32/66 ratio
Clutch Multi-plate, wet
Transmission 6-Speed Cruise Drive®
Gear Ratios (1st) 9.311
Gear Ratios (2nd) 6.454
Gear Ratios (3rd) 4.793
Gear Ratios (4th) 3.882
Gear Ratios (5th) 3.307
Gear Ratios (6th) 2.79
CHASSIS
Frame Mild steel, tubular frame; rectangular section backbone; MIG welded
Swingarm Mild steel, rectangular tube sections; MIG welded
Front Forks 49 mm with polished aluminum fork triple clamp and dual-rate springs
Rear Shocks Coil-over shock
Front Wheel 19 in. x 2.5 in. (483 mm x 64 mm)
Rear Wheel 17 in. x 4.5 in. (432 mm x 114 mm)
Brakes (Caliper Type) 4-piston fixed front, and 2-piston torque-free floating rear
Brakes (Front Rotor) 11.8 in. x .2 in. (300 mm x 5 mm)
Brakes (Rear Rotor) 11.5 in. x .23 in. (292 mm x 6 mm)
Suspension Travel (Front) 5 in. (127 mm)
Suspension Travel (Rear) 3.1 in. (78.74 mm)
PERFORMANCE
Engine Torque 92 ft. lbs. @ 3000 RPM (125 Nm @ 3000 RPM)
Lean Angle (Right) 29.5°
Lean Angle (Left) 30.9°
Fuel Economy (EPA) 34/53 mpg (6.90/4.40 L/100 km)
ELECTRIC
Battery Sealed, maintenance-free, 12V, 19-amp/hour, 270 cca
Charging Three-phase, 40-amp system (493W @ 13.5V, 2000 RPM, 540W max power @ 13.5V)
Starting 1.2 kW electric with solenoid shift starter motor engagement
Lights (Headlamp) 55-watt low beam, 60-watt high beam
Lights (Tail/Stop) 8W/28W (5W/21W)
Turn Signal Lights 28W (21W) self-canceling
Indicator Lamps High beam, directional light bar, neutral, low oil pressure, engine diagnostics, security (optional)
Electric Power Outlet Standard
WARRANTY
Warranty 24 months (unlimited mileage)
Service Interval First 1,000 miles (1,600 km), every 5,000 miles (8,000 km) thereafter
