| Dimensions |
|
| Overall length |
2085 mm (82.1 in) |
| Overall width |
745 mm (29.3 in) |
| Overall height |
1090 mm (42.9 in) |
| Seat height |
805 mm (31.7 in) |
| Wheelbase |
1400 mm (55.1 in) |
| Ground clearance |
140 mm (5.51 in) |
| Minimum turning radius |
2.7 m (8.86 ft) |
| Weight |
|
| Curb weight |
180 kg (397 lb) (FZ07H, FZ07HC), 183 kg (403 lb) (FZ07AH, FZ07AHC) |
| Engine |
|
| Combustion cycle |
4-stroke |
| Cooling system |
Liquid cooled |
| Valve train |
DOHC |
| Cylinder arrangement |
Inline |
| Number of cylinders |
2-cylinder |
| Displacement |
689 cm³ |
| Bore × stroke |
80.0 × 68.6 mm (3.15 × 2.70 in) |
| Compression ratio |
11.5 : 1 |
| Starting system |
Electric starter |
| Lubrication system |
Wet sump |
| Engine oil |
Recommended brand: YAMALUBE |
| SAE viscosity grades |
10W-40, 10W-50, 15W-40, 20W-40, 20W-50 |
| Recommended engine oil grade |
API service SG type or higher, JASO standard MA |
| Engine oil quantity |
Oil change: 2.30 L (2.43 US qt, 2.02 Imp.qt) |
|
With oil filter removal: 2.60 L (2.75 US qt, 2.29 Imp.qt) |
| Cooling System |
|
| Coolant quantity |
Coolant reservoir: 0.25 L (0.26 US qt, 0.22 Imp.qt) |
|
Radiator: 1.60 L (1.69 US qt, 1.41 Imp.qt) |
| Air Filter |
Oil-coated paper element |
| Fuel |
|
| Recommended fuel |
Regular unleaded gasoline (Gasohol [E10] acceptable) |
| Fuel tank capacity |
14 L (3.7 US gal, 3.1 Imp.gal) |
| Fuel reserve amount |
2.7 L (0.71 US gal, 0.59 Imp.gal) |
| Fuel Injection |
|
| Throttle body |
ID mark: 1WS1 00 (FZ07AH, FZ07H), 1WS1 10 (FZ07AHC, FZ07HC) |
| Spark Plugs |
Manufacturer/model: NGK/LMAR8A-9 |
| Spark plug gap |
0.8–0.9 mm (0.031–0.035 in) |
| Clutch |
Wet, multiple-disc |
| Drivetrain |
|
| Primary reduction ratio |
1.925 (77/40) |
| Secondary reduction ratio |
2.688 (43/16) |
| Transmission type |
Constant mesh 6-speed |
| Gear ratios |
1st: 2.846 (37/13), 2nd: 2.125 (34/16), 3rd: 1.632 (31/19), 4th: 1.300 (26/20), 5th: 1.091 (24/22), 6th: 0.964 (27/28) |
| Chassis |
|
| Frame type |
Diamond |
| Caster angle |
24.8 ° |
| Trail |
90 mm (3.5 in) |
| Tires |
|
| Front tire |
Tubeless, Size: 120/70 ZR 17M/C(58W), Manufacturer: MICHELIN/PILOT ROAD 3 or BRIDGESTONE/BT023F F |
| Rear tire |
Tubeless, Size: 180/55 ZR 17M/C(73W), Manufacturer: MICHELIN/PILOT ROAD 3A or BRIDGESTONE/BT023R M |
| Loading |
|
| Maximum load |
172 kg (379 lb) (FZ07AH, FZ07AHC), 175 kg (386 lb) (FZ07H, FZ07HC) |
| Tire air pressure |
Front: 225 kPa (2.25 kgf/cm², 33 psi), Rear: 250 kPa (2.50 kgf/cm², 36 psi) |
| Wheels |
|
| Front wheel type |
Cast wheel |
| Rim size |
17M/C x MT3.50 (Front), 17M/C x MT5.50 (Rear) |
| Brakes |
|
| Front brake |
Hydraulic dual disc brake, Specified brake fluid: DOT 4 |
| Rear brake |
Hydraulic single disc brake, Specified brake fluid: DOT 4 |
| Suspension |
|
| Front suspension |
Telescopic fork, Spring: Coil spring, Shock absorber: Hydraulic damper, Wheel travel: 130 mm (5.1 in) |
| Rear suspension |
Swingarm (link suspension), Spring: Coil spring, Shock absorber: Gas-hydraulic damper, Wheel travel: 130 mm (5.1 in) |
| Electrical System |
|
| System voltage |
12 V |
| Ignition system |
TCI |
| Charging system |
AC magneto |
| Battery |
Model: YTZ10S, Voltage, capacity: 12 V, 8.6 Ah (10 HR) |
| Lighting |
|
| Headlight |
Bulb type: Halogen bulb, Bulb wattage: Headlight: H4, 60.0 W/55.0 W |
| Brake/tail light |
LED |
| Front turn signal |
21.0 W/5.0 W |
| Rear turn signal |
21.0 W |
| Auxiliary light |
5.0 W |
| License plate light |
5.0 W |
| Meter lighting |
LED |
| Indicator Lights |
|
| Neutral, High beam, Oil pressure warning, Turn signal, Coolant temperature warning, Engine trouble warning, ABS (FZ07AH, FZ07AHC) |
|
| Fuses |
Main fuse: 30.0 A, Auxiliary fuse: 2.0 A, Headlight fuse: 15.0 A, Signaling system fuse: 10.0 A, Ignition fuse: 10.0 A, Parking lighting fuse: 10.0 A, Radiator fan motor fuse: 10.0 A, ABS control unit fuse: 7.5 A (FZ07AH, FZ07AHC), ABS motor fuse: 30.0 A (FZ07AH, FZ07AHC), ABS solenoid fuse: 20.0 A (FZ07AH, FZ07AHC), Backup fuse: 7.5 A, Backup fuse 2: 10.0 A |
