Yamaha Vino 125 (2004-2010) Specifications
The Yamaha Vino 125 yamaha scutic motorcycle that is sell in america and canada 2004-2010.this stylish scooter known for its retro-inspired design and practical performance. Powered by a reliable air-cooled, 4-stroke, SOHC, forward-inclined single-cylinder engine with a displacement of 125 cc carburator. The Vino 125 features both an electric starter and a kickstarter, ensuring easy ignition, while the automatic V-belt transmission
| Dimensions | |
|---|---|
| Overall Length | 1755 mm (69.1 in) |
| Overall Width | 699 mm (27.5 in) |
| Overall Height | 1063 mm (41.9 in) |
| Seat Height | 759 mm (29.9 in) |
| Wheelbase | 1230 mm (48.4 in) |
| Ground Clearance | 95 mm (3.74 in) |
| Minimum Turning Radius | 1800 mm (70.9 in) |
| Weight (With oil and fuel) | 109.0 kg (240 lb) |
| Engine | |
| Engine Type | Air cooled 4-stroke, SOHC |
| Cylinder Arrangement | Forward-inclined single cylinder |
| Displacement | 125.0 cm³ |
| Bore x Stroke | 51.5 x 60.0 mm (2.03 x 2.36 in) |
| Compression Ratio | 9.80:1 |
| Starting System | Electric starter and kickstarter |
| Lubrication System | Wet sump |
| Engine Oil Type | SAE 20W-40 or SAE 10W-30 |
| Recommended Oil | YAMALUBE 4 (10W-40) or SAE 20W-50 |
| Engine Oil Quantity (Periodic) | 1.00 L (1.06 US qt, 0.88 Imp.qt) |
| Final Transmission Oil | |
| Oil Type | SAE 85W-140 (GL5) |
| Oil Quantity | 0.13 L (0.14 US qt, 0.11 Imp.qt) |
| Air Filter | Oil-coated paper element |
| Fuel System | |
| Recommended Fuel | Unleaded gasoline only |
| Fuel Tank Capacity | 4.7 L (1.24 US gal, 1.03 Imp.gal) |
| Carburetor Type | Mikuni BS26 x 1 |
| Spark Plug | |
| Manufacturer/Model | NGK/CR7E |
| Spark Plug Gap | 0.7-0.8 mm (0.028-0.031 in) |
| Clutch | Dry, centrifugal automatic |
| Transmission | |
| Primary Reduction Ratio | 40/15 (2.666) |
| Secondary Reduction Ratio | 38/13 (2.923) |
| Transmission Type | V-belt automatic |
| Chassis | |
| Frame Type | Steel tube backbone |
| Caster Angle | – |
| Trail | 75.0 mm (2.95 in) |
| Tires | |
| Front Tire Size | 3.50-10 51J |
| Rear Tire Size | 3.50-10 51J |
| Front Tire Type | Tubeless |
| Rear Tire Type | Tubeless |
| Tire Air Pressure (Cold) | |
| Front (0-90 kg load) | 150 kPa (1.50 kgf/cm², 22 psi, 1.50 bar) |
| Rear (0-90 kg load) | 200 kPa (2.00 kgf/cm², 29 psi, 2.00 bar) |
| Front (90 kg-max load) | 150 kPa (1.50 kgf/cm², 22 psi, 1.50 bar) |
| Rear (90 kg-max load) | 225 kPa (2.25 kgf/cm², 33 psi, 2.25 bar) |
| Wheels | |
| Front Wheel Type | Cast wheel |
| Rear Wheel Type | Cast wheel |
| Rim Size (Front/Rear) | J10 x MT2.5 |
| Brakes | |
| Front Brake Type | Single disc brake |
| Rear Brake Type | Drum brake |
| Brake Fluid | DOT 3 or 4 |
| Suspension | |
| Front Suspension | Telescopic fork |
| Rear Suspension | Unit swing |
| Wheel Travel (Front) | 59.0 mm (2.32 in) |
| Wheel Travel (Rear) | 54.0 mm (2.13 in) |
| Electrical System | |
| Ignition System | CDI |
| Charging System | CDI magneto |
| Battery Model | GTX7A-BS / YTX7A-BS |
| Battery Voltage/Capacity | 12 V, 6.0 Ah |
| Lighting | |
| Headlight | 12 V, 60 W/55 W x 1 |
| Tail/Brake Light | 12 V, 8.0 W/27.0 W x 1 |
| Turn Signal Lights (Front/Rear) | 12 V, 10.0 W x 2 |
| License Plate Light | 12 V, 8.0 W x 1 |
| Meter Lighting | 14 V, 3.0 W x 1 |
| Fuses | Main fuse: 10.0 A |
source: yamaha vino 125 manual book
