2011 Harley-Davidson FXDWG DYNA WIDE GLIDE

New Paint Color Options

Solids: Vivid Black
Two-Tones: Vivid Black Flame, Chrome Yellow Flame, Sedona Orange Flame

Key Features

Black powder-coated powertrain with chrome covers
Chrome “Tommy Gun” 2-1-2 collector exhaust with dual mufflers
4.7-gallon Street Bob®-style fuel tank, raised 0.75 inches at the front
40-spoke laced steel wheels with black rims
21-inch front wheel
Lowered front and rear suspension by one inch
34-degree fork angle for a bold stance
Wide polished aluminum triple clamps
Chopped rear fender with chrome supports
Low solo seat with separate passenger pillion
Stainless steel internally-wired handlebar mounted on a 4-inch black riser
Wrinkle-black battery box and fender struts
Black mirrors and headlight bucket
Black one-piece wire sissy bar
Dual red LED lights for stop/turn/tail functions
Side-mounted license plate
Low-profile tank console with an electronic speedometer

Model Highlights

Re-introduced in 2010, the Dyna® Wide Glide® motorcycle embodies attitude with its tough, dark styling and retro feel. This bike, with a retro price tag, allows riders to sit low and stretch out in comfort.

The Wide Glide® stays true to its roots with:

A chopped rear fender
Black rims on 40-spoke laced wheels
A black tank console
“Tommy Gun” exhaust
Raked-out forks
A swept-back sissy bar

The iconic Flame paint scheme ensures that heads will turn wherever you go.

Ride Experience

This bike is about more than just looks:

Lowered suspension provides a sleek ride
Internally-wired handlebars with a 4-inch riser add to the overall aesthetics
Forward foot controls enhance comfort

And the attractive price makes it a great value for riders looking for a classic, aggressive ride.

Powertrain

Engine: Rubber-mounted Twin Cam 96™ V-Twin engine with Electronic Sequential Port Fuel Injection (ESPFI)
Torque: 92 ft. lbs.
Transmission: 6-speed Cruise Drive®
Battery: Exposed under-seat battery box
Suspension: Exposed rear coil-over shock absorbers
Foot controls: Forward-mounted rider footpegs with brake and shift levers
Optional Security: Harley-Davidson® Smart Security System with hands-free security fob

Dimensions

Length: 94.0 in. / 2388 mm
Seat Height (laden): 25.5 in. / 648 mm
Wheelbase: 68.3 in. / 1735 mm

Wheels & Tires

Front Wheel: Black, laced steel (21 in. x 2 in. / 533 mm x 55 mm)
Rear Wheel: Black, laced steel (17 in. x 5 in. / 432 mm x 114 mm)
Front Tire: Dunlop® Harley-Davidson® Series GT502 F 80/90-21 54V
Rear Tire: Dunlop® Harley-Davidson® Series GT502 180/60B17 75V

Fuel & Weight

Fuel Capacity: 4.7 U.S. gallons / 17.8 liters
Weight (as shipped): 647 lbs. / 293.5 kg

Performance

Fuel Efficiency: 54 MPG Highway / 35 MPG City
Engine: Air-cooled, Twin Cam 96™
Displacement: 96 cu in. / 1584 cc
Fuel System: Electronic Sequential Port Fuel Injection (ESPFI)
Transmission: 6-Speed Cruise Drive®

Pricing (U.S. MSRP)

Vivid Black: $14,499
Two-Tones (with Flames): $15,194

Technical Data

DIMENSIONS
Length	94.0 in. (2388 mm)
Overall Width	37.2 in. (945 mm)
Overall Height	47.8 in. (1214 mm)
Seat Height (Laden)	25.5 in. (648 mm)
Seat Height (Unladen)	26.7 in. (678 mm)
Ground Clearance	4.2 in. (107 mm)
Rake (Steering Head)	34°
Fork Angle	36°
Trail	5.2 in. (132 mm)
Wheelbase	68.3 in. (1735 mm)
Front Tire	Dunlop® GT502 F 80/90-21 54V
Rear Tire	Dunlop® GT502 180/60B17 75V
Fuel Capacity	4.7 gal. (17.8 L)
Oil Capacity (with filter)	3.0 qts. (2.8 L)
Transmission Capacity	1.0 qts.
Primary Chain Case Capacity	1.0 qts.
Weight (As Shipped)	647 lbs. (293.5 kg)
Weight (In Running Order)	665 lbs. (301.6 kg)
Gross Vehicle Weight Rating	1085 lbs. (492.2 kg)
Gross Axle Weight Rating (Front)	390 lbs. (176.9 kg)
Gross Axle Weight Rating (Rear)	695 lbs. (315.3 kg)
ENGINE
Engine	Air-cooled, Twin Cam 96™
Valves	Pushrod-operated, overhead valves, 2 per cylinder
Bore x Stroke	3.75 in. x 4.38 in. (95.3 mm x 111.3 mm)
Displacement	96 cu. in. (1584 cc)
Compression Ratio	9.2:1
Fuel System	Electronic Sequential Port Fuel Injection (ESPFI)
Air Cleaner	Fiberglass Media, washable
Lubrication System	Pressurized, dry-sump
DRIVETRAIN
Primary Drive	Chain, 34/46 ratio
Final Drive	Belt, 32/66 ratio
Clutch	Multi-plate, wet
Transmission	6-Speed Cruise Drive®
Gear Ratios (Overall)	1st: 9.311, 2nd: 6.454, 3rd: 4.793, 4th: 3.882, 5th: 3.307, 6th: 2.79
CHASSIS
Frame	Mild steel, tubular frame
Swingarm	Mild steel, rectangular tube sections
Front Forks	49 mm with polished aluminum fork triple clamp, dual-rate springs
Rear Shocks	Coil-over shock
Wheels (Front)	Black, Laced Steel 21 in. x 2.15 in. (533 mm x 55 mm)
Wheels (Rear)	Black, Laced Steel 17 in. x 4.5 in. (432 mm x 114 mm)
Front Brake (Floating)	4-piston caliper, 11.8 in. x 0.2 in. (300 mm x 5 mm) rotor
Rear Brake	2-piston caliper, 11.5 in. x 0.23 in. (292 mm x 6 mm) rotor
Suspension Travel (Front)	5 in. (127 mm)
Suspension Travel (Rear)	3.1 in. (78.74 mm)
PERFORMANCE
Engine Torque	92 ft. lbs. @ 3000 RPM (125 Nm @ 3000 RPM)
Lean Angle (Right)	28.4°
Lean Angle (Left)	31.9°
Fuel Economy (EPA Urban/Highway)	35/54 mpg (6.70/4.40 L/100 km)
ELECTRIC
Battery	Sealed, maintenance-free, 12V, 19-amp/hour, 270 cca
Charging	Three-phase, 40-amp system, 493W @ 13.5V
Starting	1.2 kW electric with solenoid shift starter motor engagement
Lights	55W low beam, 60W high beam (quartz halogen), 43W brake/turn lamp
Indicator Lamps	High beam, directional light bar, neutral, low oil pressure, engine diagnostics, turn signals, security system (optional), 6-speed, low fuel warnings
Electric Power Outlet	Standard
WARRANTY
Warranty	24 months (unlimited mileage)
Service Interval	First 1,000 miles (1,600 km), every 5,000 miles (8,000 km) thereafter
