| Dry Weight (without fuel/fluids) |
522 lb (237 kg) |
| Wet Weight (with fuel/fluids) |
542 lb (246 kg) |
| Gross Vehicle Weight Rating (GVWR) |
988 lb (449 kg) |
| Gross Axle Weight Rating (GAWR) |
Front: 371 lb (168 kg), Rear: 675 lb (306 kg) |
| Maximum Load Capacity |
446 lb (203 kg) |
| Capacities |
| Engine Oil |
With Oil Filter Change: 4.5 qt (4.26 l), New/Rebuilt Engine: 5.25 qt (4.97 l) |
| Recommended Engine Oil |
SAE 15W60 |
| Fuel |
3.4 gal (13.0 l) |
| Recommended Fuel |
91 Octane or 95 RON minimum |
| Fuel Reserve |
0.5 gal (1.9 l) |
| Fork Oil (per side – conventional) |
10.7 oz (315 cc) |
| Radiator Coolant |
0.5 gal (1.9 l) |
| Dimensions |
| Overall Length |
86.9 in (2206 mm), With Center License Plate: 89.0 in (2260 mm) |
| Overall Width |
Including Mirrors: 36.6 in (930 mm), Excluding Mirrors: 33.7 in (855 mm) |
| Overall Height |
Excluding Mirrors: 42.2 in (1071 mm) |
| Seat Height |
Un-Laden: 26.2 in (665 mm), Laden: 25.6 in (649 mm) |
| Wheelbase |
61.5 in (1562 mm) |
| Ground Clearance |
4.3 in (109 mm) |
| Rake (frame) / Trail |
29° / 4.9 in (124 mm) |
| Engine |
| Engine Type |
Liquid Cooled V-Twin (60 Degrees) |
| Displacement |
76 cid (1250 cc) |
| Compression Ratio |
12.5:1 |
| Valve Train |
DOHC, 4 Valves Per Cylinder, Graded Buckets |
| Bore and Stroke |
4.094” x 2.898” (104 mm x 73.6 mm) |
| Fuel System / Throttle Body Bore |
Closed Loop Fuel Injection / 60 mm |
| Exhaust System |
2 into 1 |
| Horsepower |
105 HP |
| Peak Torque |
82 ft-lbs |
| Peak Torque RPM |
6300 rpm |
| Rev Limit |
8500 RPM |
| Idle RPM |
1250 RPM +/- 50 RPM Fully Warm |
| Lubrication System |
Dry Sump |
| Spark Plug / Gap |
NGK® LZMAR8CI-10 / 0.039 in (1.0 mm) |
| Drive System |
| Primary Drive |
Gear Drive Wet Clutch |
| Crank Gear |
46 Teeth |
| Clutch Gear |
77 Teeth |
| Clutch Type |
Assist, Wet, Multi-Plate |
| Primary Reduction Ratio |
1:674:1 |
| Transmission Type |
6 Speed / Constant Mesh / Foot Shift |
| Gear Ratios |
1st: 2.769:1, 2nd: 1.882:1, 3rd: 1.500:1, 4th: 1.273:1, 5th: 1.125:1, 6th: 0.966:1 |
| Gear Shift Pattern |
1 Down / 5 Up |
| Final Drive Type |
Belt Drive, 146–Tooth |
| Drive Sprocket |
29–Tooth |
| Driven Sprocket |
66–Tooth |
| Final Drive Ratio |
2.276:1 |
| Overall Gear Ratio |
1st: 10.550:1, 2nd: 7.171:1, 3rd: 5.714:1, 4th: 4.849:1, 5th: 4.286:1, 6th: 3.678:1 |
| Chassis |
| Front Suspension |
Telescopic Fork / 4.7 in (120 mm) |
| Front Fork Tube Diameter |
41 mm |
| Rear Suspension |
Dual Shocks / 2 in (51 mm) |
| Swingarm |
Steel |
| Brakes |
Front Brakes Single / 298 mm Rotor / 2 Piston Caliper. Rear Brakes Single / 298 mm Rotor / 1 Piston Caliper |
| Electrical |
| Stator |
660W @ 5000 RPM |
| Battery |
12 volt, 18 amp-hour, 310 CCA, Maintenance Free AGM |
| Voltage Regulator |
14.5 volts / 55 amp |
| Lamps |
Non-Serviceable LED |
| Wheels and Tires |
| Front Wheel Size / Type |
16 in x 3.5 in Cast 8-Spoke |
| Rear Wheel Size / Type |
16 in x 3.5 in Cast 8-Spoke |
| Front Tire |
Pirelli® MT60RS 130 / 90B16 67H Alternative: Kenda® K673 130 / 90B16 73H |
| Rear Tire |
Pirelli® MT60RS 150 / 80B16 77H Alternative: Kenda® K673 150 / 80B16 71H |
| Features |
| Color / Graphics |
Black Metallic |
| Factory Warranty |
2 Years, Unlimited Miles |
| Gauge |
Analog Speedometer, Digital Tachometer, Odometer, Trip Meter, Lamp Fuel Gauge, Fuel Range, Fuel Economy, Gear Position, Clock, Ambient Temp, Battery Voltage |
| Infotainment |
N/A |
| Lights |
LED Headlight, tail/brake light, turn signals, license plate light |
| Standard Equipment |
ABS |
