Yamaha TT-R110E Maintenance
Periodic maintenance chart for the emission control system
Contents
hide
TIP
- From 7000 km (4200 mi) or 18 months, repeat the maintenance intervals starting from 3000 km (1800 mi) or 6 months.
- Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and tech- nical skills.
| No. | ITEM | CHECKS AND MAINTENANCE JOBS | INITIAL | ODOMETER READINGS | ||
| 1000 km (600 mi) or 1 month or 30 hours |
3000 km (1800 mi) or 6 months or 90 hours |
5000 km (3000 mi) or 12 months or 150 hours |
||||
| 1 | * | Fuel line | • Check fuel hoses for cracks or damage. • Replace if necessary |
✔️ | ✔️ | |
| 2 | Spark plug | • Check condition. • Adjust gap and clean. |
✔️ | ✔️ | ||
| 3 | * | Valve clearance | • Check operation. • Adjust brake pedal free play and replace brake shoes if necessary. |
✔️ | ||
| 4 | Air filter element | • Clean with solvent. • Replace if necessary |
✔️ | ✔️ | ||
| 5 | * | Crankcase breather sys- tem | • Check ventilation hose for cracks or damage and drain any deposits. • Replace if necessary. |
✔️ | ✔️ | ✔️ |
| 6 | * | Carburetor | • Check engine idling speed and starter operation. • Adjust if necessary | ✔️ | ✔️ | ✔️ |
| 7 | Exhaust system | • Check for leakage. • Tighten if necessary. • Replace gasket(s) if necessary |
✔️ | ✔️ | ||
| 8 | * | Spark arrester | • Clean. | ✔️ | ||
| 9 | Engine oil | • Change (warm engine before draining). | ✔️ | ✔️ | ✔️ | |
General maintenance and lubrication chart
TIP
- From 7000 km (4200 mi) or 18 months, repeat the maintenance intervals starting from 3000 km (1800 mi) or 6 months.
- Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and tech- nical skills.
| No. | ITEM | CHECKS AND MAINTENANCE JOBS | INITIAL | ODOMETER READINGS | ||
| 1000 km (600 mi) or 1 month or 30 hours |
3000 km (1800 mi) or 6 months or 90 hours |
5000 km (3000 mi) or 12 months or 150 hours |
||||
| 1 | * | Clutch | Check operation. Adjust if necessary. |
✔️ | ✔️ | ✔️ |
| 2 | * | Front brake | Check operation. Adjust brake lever free play and replace brake shoes if necessary. |
✔️ | ✔️ | ✔️ |
| 3 | * | Rear brake | Check operation. Adjust brake pedal free play and replace brake shoes if necessary. |
✔️ | ✔️ | ✔️ |
| 4 | * | Wheels | Check runout, spoke tightness and for damage. Tighten spokes if necessary. |
✔️ | ✔️ | ✔️ |
| 5 | * | Tires | Check tread depth and for damage. Replace if necessary. Check air pressure. Correct if necessary. |
✔️ | ✔️ | |
| 6 | * | Wheel bearings | Check bearings for smooth operation. Replace if necessary. |
✔️ | ✔️ | |
| 7 | * | Swingarm pivot bushes | Check bush assemblies for looseness. Lubricate with molybdenum disulfide grease. |
✔️ | ✔️ | |
| 8 | Drive chain | Check chain slack/alignment and condition. Adjust and lubricate chain with Yamaha chain lubricant or other suitable chain lubricant thoroughly. |
Every ride | |||
| 9 | * | Steering bearings | Check bearing assemblies for looseness. Moderately repack with lithium-soap-based grease. |
✔️ | ✔️ | |
| 10 | * | Chassis fasteners | Check all chassis fitting and fasteners. Correct if necessary. |
✔️ | ✔️ | ✔️ |
| 11 | Brake lever pivot shaft | Apply lithium-soap-based grease lightly. | ✔️ | ✔️ | ||
| 12 | Brake pedal pivot shaft | Apply lithium-soap-based grease lightly. | ✔️ | ✔️ | ||
| 13 | Sidestand pivot | Check operation. Apply lithium-soap-based grease lightly. |
✔️ | ✔️ | ||
| 14 | * | Front fork | Check operation and for oil leakage. Replace if necessary. |
✔️ | ✔️ | |
| 15 | * | Shock absorber assem- bly |
Check operation and for oil leakage. Replace if necessary. |
✔️ | ||
| 16 | * | Control cables | Apply Yamaha cable lubricant or other suitable cable lu- bricant thoroughly. | ✔️ | ✔️ | ✔️ |
| 17 | * | Throttle grip | Check operation. Check throttle grip free play, and adjust if necessary. Lubricate cable and grip housing. |
✔️ | ✔️ | ✔️ |
TIP
- The air filter needs more frequent service if you are riding in unusually wet or dusty areas.
